PA midrange speaker 300W MAX, 8 Ohm
Code: MZMSP6150PA
£41.74
(£34.78
ex VAT)
Quantity Pricing
2
-
4
£41.42
each
(£34.52
each ex VAT)
5
+
£41.11
each
(£34.26
each ex VAT)
-
VAT
Out of Stock
Please enter your email address below and we will notify you once this item is back in stock.
Description
PA midrange speaker, 300WMAX, 150WRMS, 8Ω
For PA midrange applications of high power rating with the use of mid-high range horns at the same time. Very well-suited for dual arrangements.
IMG STAGE LINE product code: SP-6/150PA
Details
TECHNICAL DATA:
| Impedance (Z) | 8Ω |
| Resonant frequency (fs) | 73Hz |
| Max. frequency range | f3-6,000Hz |
| Music power | 300WMAX |
| Power rating (P) | 150WRMS |
| SPL (1W/m) | 93dB |
| Suspension compl. (Cms) | 0.31mm/N |
| Moving mass (Mms) | 15.2g |
| Mech. Q factor (Qms) | 5.31 |
| Electr. Q factor (Qes) | 0.46 |
| Total Q factor (Qts) | 0.42 |
| Equivalent volume (Vas) | 8.5 l |
| DC resistance (Re) | 6.5Ω |
| Force factor (BxL) | 9.9Tm |
| Voice coil induct. (Le) | 0.6mH |
| Voice coil diameter | 50mm |
| Voice coil former | Kapton |
| Linear excursion (XMAX) | ±1mm |
| Eff. cone area (Sd) | 139cm2 |
| Magnet weight | 850g |
| Weight | 2.1kg |
