PA bass speaker, 38cm, 800W MAX, 8 Ohm
Code: MZMSP15A402PA
£221.47
(£184.56
ex VAT)
Quantity Pricing
2
+
£217.98
each
(£181.65
each ex VAT)
-
VAT
Choose quantity
Order now for dispatch on Wed 4th Mar.
Description
Professional PA bass speaker, 800WMAX, 400WRMS, 8Ω, 38cm (15")
This speaker is of very high power capability, high efficiency and has drive parameters which allow a reproduction of the complete bass range.
It guarantees excellent results as bass-midrange speakers in 2-way or multi-way systems as well as subwoofers with the two larger models.
- Of very high power capability
- 38 cm (15") professional bass speaker of long excursion
- Diecast basket
- Cone with water-repellent coating
- Very neat workmanship with a facing basket front
- Wide frequency response
- High efficiency
- Excellent deep bass reproduction
- Drive system with drilled pole core and additional magnet for optimising the magnetic field and impedance linearisation
- For bass-reflex cabinets of medium size from 80 litres on
- For all kinds of professional and semiprofessional PA applications
IMG STAGE LINE product code: SP-15A/402PA
Details
TECHNICAL DATA:
| Impedance (Z) | 8Ω |
| Resonant frequency (fs) | 36Hz |
| Max. frequency range | f3-3,000Hz |
| Music power | 800WMAX |
| Power rating (P) | 400WRMS |
| SPL (1W/m) | 100dB |
| Suspension compl. (Cms) | 0.22mm/N |
| Moving mass (Mms) | 87g |
| Mech. Q factor (Qms) | 7.45 |
| Electr. Q factor (Qes) | 0.33 |
| Total Q factor (Qts) | 0.31 |
| Equivalent volume (Vas) | 235 l |
| DC resistance (Re) | 6.5Ω |
| Force factor (BxL) | 19.9Tm |
| Voice coil induct. (Le) | 0.9mH |
| Voice coil diameter | 100mm |
| Voice coil former | Kapton |
| Linear excursion (XMAX) | ±5mm |
| Eff. cone area (Sd) | 881cm2 |
| Magnet weight | 2.3kg |
| Weight | 8kg |
