PA bass-midrange speaker, 25cm, 600W MAX, 8 Ohm
Code: MZMSP10A302PA
£148.63
(£123.86
ex VAT)
Quantity Pricing
3
+
£141.20
each
(£117.67
each ex VAT)
-
VAT
Choose quantity
Order now for dispatch on Wed 4th Mar.
Description
Professional PA bass-midrange speaker, 600Wmax, 300Wrms, 8Ω, 25cm (10")
This speaker is of very high power capability, high efficiency and has drive parameters which allow a reproduction of the complete bass range.
It guarantees excellent results as bass-midrange speakers in 2-way or multi-way systems as well as subwoofers with the two larger models.
- Of very high power capability
- 25 cm (10") professional speaker of long excursion
- Diecast basket
- Cone with water-repellent coating
- Very neat workmanship with a facing basket front
- Wide frequency response of low distortion
- High efficiency
- Drive system with drilled pole core and additional magnet for optimising the magnetic field and impedance linearisation
- For compact bass-reflex cabinets from 20 litres on already
- For all kinds of professional and semi-professional PA applications
IMG STAGE LINE product code: SP-10A/302PA
Details
TECHNICAL DATA:
| Impedance (Z) | 8Ω |
| Resonant frequency (fs) | 55Hz |
| Max. frequency range | f3-3,500Hz |
| Music power | 600WMAX |
| Power rating (P) | 300WRMS |
| SPL (1W/m) | 98dB |
| Suspension compl. (Cms) | 0.24mm/N |
| Moving mass (Mms) | 35g |
| Mech. Q factor (Qms) | 7.44 |
| Electr. Q factor (Qes) | 0.31 |
| Total Q factor (Qts) | 0.30 |
| Equivalent volume (Vas) | 40 l |
| DC resistance (Re) | 6.4Ω |
| Force factor (BxL) | 15.82Tm |
| Voice coil induct. (Le) | 0.65mH |
| Voice coil diameter | 66mm |
| Voice coil former | Kapton |
| Linear excursion (XMAX) | ±4mm |
| Eff. cone area (Sd) | 346cm2 |
| Magnet weight | 2kg |
| Weight | 5kg |
