Full range speaker, 60W MAX, 4 Ohm
Code: MZMSPM200X4
£28.72
(£23.93
ex VAT)
Quantity Pricing
2
-
4
£27.68
each
(£23.07
each ex VAT)
5
+
£27.28
each
(£22.73
each ex VAT)
-
VAT
Out of Stock
Please enter your email address below and we will notify you once this item is back in stock.
Description
Full range speaker, 60WMAX, 30WRMS, 4Ω
Efficient full range speaker for general PA applications and Hi-Fi applications.
- Sheet steel basket
- Paper cone with dual cone
- Wide frequency response
- Subwoofer support required for Hi-Fi applications
MONACOR product code: SPM-200X/4
Details
| TECHNICAL DATA: | |
| Impedance (Z) | 4 Ω |
| Resonant frequency (fs) | 89 Hz |
| Max. frequency range | f3-15,000 Hz |
| Music power | 60 WMAX |
| Power rating (P) | 30 WRMS |
| SPL (1 W/m) | 94 dB |
| Suspension compl. (Cms) | 0.27 mm/N |
| Moving mass (Mms) | 9.9 g |
| Mech. Q factor (Qms) | 2.69 |
| Electr. Q factor (Qes) | 1.52 |
| Total Q factor (Qts) | 0.97 |
| Equivalent volume (Vas) | 14.9 l |
| DC resistance (Re) | 3.7 Ω |
| Force factor (BxL) | 3.9 Tm |
| Voice coil induct. (Le) | 0.2 mH |
| Voice coil diameter | 25 mm |
| Voice coil former | aluminium |
| Linear excursion (XMAX) | ±1 mm |
| Eff. cone area (Sd) | 201 cm2 |
| Magnet weight | 229 g |
| Weight | 0.7 kg |
